Full Scale Deflection Obtained With 1ppm Quinine Sulphate In 0.1 N Sulphuric Acid (Primary Wavelength 360nm) Primary Filters: Corning 5840 And Corning 5113 Mounted Holders. Secondary Filters: Corning 4308, Corning 3486, And Corning 3385 Mounted On Holders. It Is Used For Analysis Of Fluorohors Such As Vitamins, Quinine, Steroids, Fluorescein, Metal Complexes Etc.
Display:- 3 Digit Bright Red Seven Segment Led Display
Excitation Source:- 12v, 50w Tungsten Halogen Lamp
Sensitivity Ranges:- Adjustable In 4 Ranges
Primary Filters:-Corning 5840 And Corning 5113 Mounted On Holders
Secondary Filters:- Corning 4308, Corning 3486, Corning 3385 Mounted On Holders
Detector:- Highly Sensitive Wide Range Photodiode/Dell
Samples Test Tube:-15mm (D) X 80 Mm (H)
Minimum Sample:- 4ml
Power:- 230v + 10%, 50 Hz. Ac
